2D Floor plans
2D Elevation & Sections
Structural Drawings
Good For Construction Drawings
Soil Test Report
Steel: FE 500 Gopala TMT Bars
Cement: OPC 53 Grade Bharti/Priya Brand
Concrete: M20 & M25 Grade
Masonry: 4 Inches & 6 Inches Solid Blocks
Floor To Floor Height: 10 Feet
Water Proofing: Dr Fixit Brand
Sand: Manufactured Sand & Plastering Sand
Aggregates: 20mm and 40mm
Internal Plastering: 15mm Thick Plaster
External Plastering: 20mm Thick Plaster
Flooring: Vitrified Tiles Worth Rs. 45/sqft
Electrical Points: Light, Fan and Charger Points.
Flooring: Vitrified Tiles Worth Rs. 45/sqft
Electrical Points: Light, Fan and Charger Points.
Flooring: Granite Worth Rs. 65/sqft
Fabrication: MS Railings
Type: Waist Slab Staircase
Windows: Aluminium 2-Track Windows with MS Grills Fitted.
Ventilators: Aluminium Louvered Ventilator with MS Grills Fitted.
Counter Top: Granite 20mm Thick worth Rs. 100/sqft
Backsplash Tile: 2 Feet Height Ceramic Tiles Worth Rs.40/sqft
Kitchen Sink: SS Sink with Faucet worth Rs.3500
Electrical Points: Light, Exhaust, Heating and Grinder Points.
Flooring: Vitrified Tiles Worth Rs. 45/sqft
Wall Tiles: 7 Feet Height Ceramic Tiles Worth Rs.40/sqft
Flooring Tiles: Anti Skid Tiles Worth Rs.35/sqft
Sanitary Fittings: EWC, Wash Basin, Health Faucet, Basin Faucet, Wall Mixer, Overhead Shower.
Fittings Brand: Cera or Equavalent
Electrical Points: Light and Geyser Points.
Main Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 20,000 per Door
Pooja Door: Sal Wood Frame, Laminated Shutter and Door Fittings Worth Rs. 12,000 per Door.
Internal Doors: Frame, Shutter and Door Fittings Worth Rs. 9000 per Door
Electrical Wires: Finolex/Anchor
Electrical Switches: Anchor/Cona
Plumbing Pipes: Astral
Parking And Balcony Tiles: Anti-Skid Ceramic Tiles of Worth Rs. 35/Sqft
Overhead Tank: Double Layer Tank
Internal Paint: 2 Coats of Putty, Asian Internal Primer And 2 Coats of Asian Tractor Emulsion Paint.
External Paint: 1 Coat of External Primer and 2 Coats of Asian Ace Paint.
Grills and Railings: 1 Coat of Primer and 2 Coats of Enamel Paint.
Waterproofing Warranty: 10 Years
Maintenance Warranty: 1 Year
2D Floor plans
3D Elevation & Sections
Working drawings
Structural Drawings
Good For Construction Drawings
Soil Test Report
Steel: FE 500 Sunvik - A1 Gold TMT Bars
Cement: OPC 53 Ramco/Dalmia
Concrete: M20 & M25 Grade
Masonry: 4 Inches & 6 Inches Solid Blocks
Floor To Floor Height: 10 Feet
Water Proofing: Dr Fixit Brand
Sand: Manufactured Sand & Plastering Sand
Aggregates: 20mm and 40mm
Internal Plastering: 15mm Thick Plaster
External Plastering: 20mm Thick Plaster
Flooring: Vitrified Tiles Worth Rs. 50/sqft
Electrical Points: Light, Fan, AC and Charger Points.
Flooring: Vitrified Tiles Worth Rs. 50/sqft
Electrical Points: Light, Fan, TV and Charger Points.
Flooring: Granite Worth Rs. 75/sqft
Fabrication: MS Railings
Type: Waist Slab Staircase
Windows: Aluminium 3-Track Windows with MS Grills Fitted.
Ventilators: Aluminium Louvered Ventilator with MS Grills Fitted.
Counter Top: Granite 20mm Thick worth Rs. 120/sqft
Backsplash Tile: 2 Feet Height Ceramic Tiles Worth Rs.45/sqft
Kitchen Sink: SS Sink with Faucet worth Rs.4500
Electrical Points: Light, Exhaust, Heating, Chimney and Grinder Points.
Flooring: Vitrified Tiles Worth Rs. 50/sqft
Wall Tiles: 7 Feet Height Ceramic Tiles Worth Rs.45/sqft
Flooring Tiles: Anti Skid Tiles Worth Rs.40/sqft
Sanitary Fittings: EWC, Wash Basin, Health Faucet, Basin Faucet, Wall Mixer, Overhead Shower.
Fittings Brand: Cera or Equavalent
Electrical Points: Light, Exhaust and Geyser Points.
Main Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 25,000 per Door
Pooja Door: Sal Wood Frame, Laminated Shutter and Door Fittings Worth Rs. 17,500 per Door.
Internal Doors: Frame, Shutter and Door Fittings Worth Rs. 10500 per Door
Electrical Wires: Finolex/Anchor
Electrical Switches: Anchor/Cona
Plumbing Pipes: Astral
Parking And Balcony Tiles: Anti-Skid Ceramic Tiles of Worth Rs. 40/Sqft
Overhead Tank: Double Layer Tank
Compound Wall: 4 Feet Height from Ground Floor Level.
Parapet Wall: 3 Feet 6 Inches Height From Terrace Floor Level
Gate: MS Gate Upto 5 Feet Height From Parking Floor Level
Internal Paint: 2 Coats of Putty, Asian Internal Primer And 2 Coats of Asian Tractor Emulsion Paint.
External Paint: 1 Coat of External Primer and 2 Coats of Asian Apex Paint.
Grills and Railings: 1 Coat of Primer and 2 Coats of Enamel Paint.
Door Polish: Melamine Polish or PU Polish
Waterproofing Warranty: 10 Years
Maintenance Warranty: 1 Year
2D Floor plans
3D Elevation & Sections
Working drawings
Furniture Layout
Structural Drawings
Good For Construction Drawings
Soil Test Report
Steel: FE 500 Meenakshi/Kamdhenu TMT Bars
Cement: OPC 53 Grade ACC/Zuari Brand
Concrete: M20 & M25 Grade
Masonry: 4 Inches & 6 Inches Hydraulic Punched Solid Blocks
Floor To Floor Height: 10 Feet
Sand: Manufactured Sand & Plastering Sand
Aggregates: 20mm and 40mm
Internal Plastering: 15mm Thick Plaster
External Plastering: 20mm Thick Plaster
Water Proofing: Dr Fixit/Fosroc Brand
Flooring: Vitrified Tiles Worth Rs. 60/sqft
Electrical Points: Light, Fan, AC, Bed Side and Charger Points.
Flooring: Vitrified Tiles Worth Rs. 75/sqft
Electrical Points: Light, Fan, TV, Internet and Charger Points.
Flooring: Granite Worth Rs. 90/sqft
Fabrication: MS Railings
Type: Waist Slab Staircase
Windows: UPVC 3-Track Windows with MS Grills Fitted.
Ventilators: UPVC Louvered Ventilator with MS Grills Fitted.
Counter Top: Granite 20mm Thick worth Rs. 150/sqft
Backsplash Tile: 2 Feet Height Ceramic Tiles Worth Rs.50/sqft
Kitchen Sink: SS Sink with Faucet worth Rs.6000
Electrical Points: Light, Exhaust, Heating, Chimney, Oven and Grinder Points.
Flooring: Vitrified Tiles Worth Rs. 60/sqft
Wall Tiles: 7 Feet Height Ceramic Tiles Worth Rs.50/sqft
Flooring Tiles: Anti Skid Tiles Worth Rs.45/sqft
Sanitary Fittings: Concealed EWC, Wash Basin, Health Faucet, Basin Faucet, Wall Mixer, Overhead Shower
Fittings Brand: Parryware or Hindware
Electrical Points: Light, Exhaust, Dryer and Geyser Points.
Main Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 35,000 per Door.
Pooja Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 25,000 per Door
Internal Doors: Frame, Shutter and Door Fittings Worth Rs. 12,000 per Door
Electrical Wires: Anchor/Polycab
Electrical Switches: HiFi/GM
Plumbing Pipes: Ashirvad/Supreme
Parking And Balcony Tiles: Anti-Skid Ceramic Tiles of Worth Rs. 45/Sqft
Overhead Tank: Triple Layer Tank
Compound Wall: 4 Feet Height from Ground Floor Level.
Parapet Wall: 3 Feet 6 Inches Height From Terrace Floor Level
Gate: MS Gate Upto 5 Feet Height From Parking Floor Level
UG Sump: 7000 Litres Capacity
Elevation: Texture Paint
Internal Paint: 2 Coats of Putty, Asian Internal Primer And 2 Coats of Asian Premium Emulsion Paint.
External Paint: 1 Coat of External Primer and 2 Coats of Asian Apex Paint.
Grills and Railings: 1 Coat of Primer and 2 Coats of Enamel Paint.
Door Polish: Melamine Polish or PU Polish.
Waterproofing Warranty: 10 Years
Maintenance Warranty: 1 Year
2D Floor plans
3D Elevation & Sections
Working drawings
Furniture Layout
Schedule Of Openings
Electrical & Plumbing Layout
Structural Drawings
Good For Construction Drawings
Soil Test Report
Steel: FE 500 Indus/JSW TMT Bars
Cement: OPC 53 Grade ACC/Birla Brand
Concrete: M20 & M25 Grade
Masonry: 4 Inches & 6 Inches Solid Blocks Of Brand Shobha/Apco
Floor To Floor Height: 10 Feet
Sand: Manufactured Sand & Plastering Sand
Aggregates: 20mm and 40mm
Internal Plastering: 15mm Thick Plaster
External Plastering: 20mm Thick Plaster
Water Proofing: Dr Fixit/Fosroc Brand
Flooring: Vitrified Tiles Worth Rs. 75/sqft
Electrical Points: Light, Fan, AC, Bed Side and Charger Points.
Flooring: Vitrified Tiles/Granite Worth Rs. 120/sqft
Electrical Points: Light, Fan, TV, Internet, AC, Foot Lamps and Charger Points.
False Ceiling: Periferal False Ceiling With Lighting.
Flooring: Granite Worth Rs. 120/sqft
Fabrication: SS Railings
Type: Chain Link Staircase
Windows: UPVC 3-Track Windows with MS Grills Fitted.
Ventilators: UPVC Louvered Ventilator with MS Grills Fitted.
Counter Top: Granite 30mm Thick worth Rs. 160/sqft
Backsplash Tile: 2 Feet Height Ceramic Tiles Worth Rs.60/sqft
Kitchen Sink: SS Sink/ Quartz Sink with Faucet worth Rs.8000
Electrical Points: Light, Exhaust, Heating, Chimney, Oven, Dish Washer and Grinder Points.
Flooring: Vitrified Tiles Worth Rs. 75/sqft
Wall Tiles: 7 Feet Height Ceramic Tiles Worth Rs.60/sqft
Flooring Tiles: Anti Skid Tiles Worth Rs.60/sqft
Sanitary Fittings: Concealed EWC, Granite Counter Top Wash Basin, Health Faucet, Basin Faucet, Diverter, Overhead Shower, Towel Rod, Soap Dish.
Fittings Brand: Jaquar or Equavalent
Electrical Points: Light, Exhaust, Dryer, Mirror Light and Geyser Points.
Main Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 45,000 per Door.
Pooja Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 35,000 per Door
Internal Doors: Frame, Shutter and Door Fittings Worth Rs. 15,000 per Door
Electrical Wires: Anchor/Polycab
Electrical Switches: GM or Equavalent
Plumbing Pipes: Ashirvad/Supreme
Parking And Balcony Tiles: Anti-Skid Ceramic Tiles of Worth Rs. 55/Sqft
Overhead Tank: Triple Layer Tank
Compound Wall: 4 Feet Height from Ground Floor Level.
Parapet Wall: 3 Feet 6 Inches Height From Terrace Floor Level
Gate: MS Gate Upto 5 Feet Height From Parking Floor Level
UG Sump: 10,000 Litres Capacity
Elevation: Tile Cladding
Internal Paint: 2 Coats of Putty, Asian Internal Primer And 2 Coats of Asian Paints Royale Emulsion Paint.
External Paint: 1 Coat of External Primer and 2 Coats of Asian Apex Ultima Paint.
Grills and Railings: 1 Coat of Primer and 2 Coats of Enamel Paint.
Door Polish: Melamine Polish or PU Polish
Waterproofing Warranty: 10 Years
Maintenance Warranty: 1 Year
2D Floor plans
3D Elevation & Sections
Working drawings
Furniture Layout
Schedule Of Openings
3D Walkthrough Video
3D Interior Design
Electrical & Plumbing Layout
Structural Drawings
Good For Construction Drawings
Soil Test Report
Steel: FE 500 TATA/JSW TMT Bars
Cement: OPC 53 Grade Ultra Tech/Birla Brand
Concrete: M20 & M25 Grade
Masonry: 4 Inches & 6 Inches Solid Blocks Of Brand Shobha/Apco
Floor To Floor Height: : 10 Feet
Sand: Manufactured Sand & Plastering Sand
Aggregates: 20mm and 40mm
Internal Plastering: 15mm Thick Plaster
External Plastering: 20mm Thick Plaster
Water Proofing: Dr Fixit/Fosroc Brand
Flooring: Vitrified Tiles/Granite Worth Rs. 120/sqft
Electrical Points: Light, Fan, AC, TV, Vaccum Cleaner, Bed Side, Internet and Charger Points.
Flooring: Vitrified Tiles/Granite Worth Rs. 150/sqft
Electrical Points: Light, Fan, TV, Internet, AC, Foot Lamps, Vaccum Cleaner, Home Theatre and Charger Points.
False Ceiling: Periferal False Ceiling With Lighting.
Flooring: Granite Worth Rs. 150/sqft
Fabrication: SS Railings With Toughened Glass
Type: Chain Link Staircase
Windows: UPVC 3-Track Windows with MS Grills Fitted Or Wooden Windows.
Ventilators: UPVC Louvered Ventilator with MS Grills Fitted Or Wooden Ventilators.
Counter Top: Granite 30mm Thick worth Rs. 175/sqft
Backsplash Tile: 2 Feet Height Ceramic Tiles Worth Rs.75/sqft
Kitchen Sink: SS Sink/Quartz Sink with Faucet worth Rs.10,000
Electrical Points: Light, Exhaust, Heating, Chimney, Oven, Dish Washer and Grinder Points.
Flooring: Vitrified Tiles/Granite Worth Rs. 100/sqft
Wall Tiles: 7 Feet Height Ceramic Tiles Worth Rs.75/sqft
Flooring Tiles: Anti Skid Tiles Worth Rs.65/sqft
Sanitary Fittings: Concealed EWC, Granite Counter Top Wash Basin, Health Faucet, Basin Faucet, Diverter, Overhead Shower, Towel Rod, Soap Dish.
Fittings Brand: Jaquar/Kohler
Electrical Points: Light, Exhaust, Dryer, Mirror Light and Geyser Points.
Main Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 60,000 per Door.
Pooja Door: Teak Wood Frame, Shutter and Door Fittings Worth Rs. 45,000 per Door
Internal Doors: Frame, Shutter and Door Fittings Worth Rs. 18,000 per Door
Electrical Wires: Havells/Polycab
Electrical Switches: Legrand/GM
Plumbing Pipes: Ashirvad/Supreme
Parking And Balcony Tiles: Anti-Skid Ceramic Tiles of Worth Rs. 65/Sqft
Overhead Tank: Triple Layer Tank
Compound Wall: 4 Feet Height from Ground Floor Level.
Parapet Wall: 3 Feet 6 Inches Height From Terrace Floor Level
Gate: MS Gate Upto 7 Feet Height From Parking Floor Level
UG Sump: 12,000 Litres Capacity
Elevation: Tile Cladding
Internal Paint: 3 Coats of Putty, Asian Internal Royale Primer And 2 Coats of Asian Royale Emulsion Paint.
External Paint: 1 Coat of External Primer and 2 Coats of Asian Ultima Paint.
Grills and Railings: 1 Coat of Primer and 2 Coats of Enamel Paint.
Door Polish: Melamine Polish or PU Polish
Waterproofing Warranty: 10 Years
Maintenance Warranty: 1 Year
